G31 Grey 1356 6L

Brand: BKHD
Model: G31 Grey 1356 6L
Chipset: BKHD-1356NP-12-6L
Network port:
Intel 82574L Gigabit Ethernet
Memory: 2*DDR4-SODIMM
Storage: 1*mSATA/1*SATA
Expandable slots:
1*mPCIe for WiFi/BT/4G module
Video output: 1*HD
Power supply: DC 12V 6A

Optional Processor

Intel Celeron 3867U Cores: 2 Threads: 2

Intel Core i3-7100U Cores: 2 Threads: 4

Related Attachments (Click to download)

Product Manual

Product Specifications

BIOS file

Product Features:

The BKHD G31 Grey 1356 6L is a high-performance network device that can meet the needs of a wide range of application scenarios, from network equipment, small business servers, industrial control, security surveillance, IoT gateways and corporate offices.
Powered by the 7th generation Celeron Core processor and equipped with 6 Intel 82574L chips, it offers a robust Gigabit network connection and is suitable for high throughput and high concurrency network environments.
Supports dual channel memory configurations up to 32GB, improving memory bandwidth and system performance and meeting multi-tasking requirements.
Offers 1 mPCIe slot that supports WiFi, Bluetooth and 4G modules, providing wireless connectivity options and increasing the connectivity flexibility of the device.
Offers 1 HD display output, suitable for multimedia and monitoring applications, and supports high resolution display devices. can provide excellent performance and reliable services, making it the best solution for your enterprise network and data management.

Application scenarios:

Firewall and router: Multi-NIC configuration acts as an enterprise-class firewall and router, providing high-performance network security and traffic management.
Load Balancer: Multi-NIC supports load balancing function to improve network bandwidth utilisation and reliability.
File Server: Centrally store and manage corporate files, support concurrent multi-user access and improve the efficiency of file sharing and collaboration.
Data acquisition and processing: High-performance network interface and powerful processing capabilities suitable for industrial data acquisition and processing tasks.
Remote monitoring and management: Supports wireless connectivity modules that provide remote monitoring and management capabilities suitable for industrial automation systems.
Video Surveillance Server: Multiple network cards and high-performance processors suitable as the core of the video surveillance system, supporting processing and storage of multiple high-definition video streams.
IoT device management: supports multiple network connections and wireless modules, suitable as an IoT gateway, connecting and managing multiple IoT devices.
Mini office server: efficient memory and storage configuration, suitable as a small business office server, providing file and application services.
Computing endpoint: Used as a computing endpoint, providing powerful data processing and analytics capabilities to support daily business operations.
