G30S 1090 4L

Brand BKHD
Model G30S 1090 4L
Chipset BKHD-1090NP-12-4L V1.7
Network port Intel i226 2.5G
Memory 2*DDR4 SO-DIMM
Storage 1*NVMe/1*SATA
Expandable 1*mPCIe for WiFi/BT/4G module
Video output 1*DP/1*HD
Power Adapter DC 12V-4A

Optional Processor

Model: Celeron N4000 / J4125

Cores: 2/4

Threads: 2/4

Related Attachments (Click to download)

Product Manual

Product Specifications

BIOS file

Product Features:

The G30S 1090 4L from BKHD is a multi-port mini host. Not only does this host offer good performance, but it is also designed with the user experience in mind.

Flexible processor choice: With the built-in Intel Gemini Lake Refresh Series Celeron processor, users can choose the appropriate processor according to their needs to meet the requirements of different scenarios, whether it is daily office or light data processing, they can easily cope with it.

Adequate memory resources: The device supports dual-channel DDR4 memory with maximum memory support of 16GB, providing sufficient resources for processing large amounts of data and complex applications. The high-speed performance of DDR4 memory ensures efficient and smooth data processing.

Flexible storage options: 1x M.2 NVMe slot and 1x SATA slot provide users with flexible storage options to easily meet different storage needs. Whether it is a high-speed NVMe SSD or a high-capacity SATA hard disk drive, it can meet users' storage needs.

High-speed networking experience: 4x latest Intel i226 2.5G network cards provide unparalleled high-speed networking experience for connected devices, whether it is home entertainment, office work or professional-level networking applications, you can enjoy stable and fast data transfer. High-speed network connection ensures efficiency and stability of data transfer.

Ultra-quiet design: The fanless design not only ensures the quiet operation of the unit, but also improves the stability and reliability of the unit. It creates a comfortable working environment for users and also prolongs the life of the device.
