1744NP-12-4L MB

Optional Processor

Pentium 8505 Cores: 5 Threads: 6
Core i3-1215U Cores: 6 Threads: 8
Core i5-1245U Cores: 10 Threads: 12
Core i7-1265U Cores: 10 Threads: 12

Related Attachments (Click to download)

Motherboard Specifications

BIOS file

Product Features:

Equipped with 12th generation Alder Lake series processor, it offers a variety of processor options from Pentium to high-performance Core i7 to meet different performance requirements.
Equipped with 4-port Intel i226 2.5G Ethernet, it provides up to 2.5Gbps network bandwidth, backward compatible with 10/100/1000Mbps, and is suitable for a variety of network application environments.
Supports up to 64GB of dual-channel DDR4 SO-DIMM memory, providing sufficient memory bandwidth and performance, suitable for multi-tasking and high-bandwidth application scenarios.
Provides 1 high-speed M.2 2280 SSD (PCIe/SATA protocol compliant) and 1 SATA storage interface that can be flexibly configured to meet storage needs.
Includes 1 mPCIe slot that supports WiFi/BT or 4G module, providing wireless connectivity options for devices and increasing device connectivity flexibility.
Provides 1 DP and 1 HD video output interface. Supports multi-monitor configuration, suitable for application scenarios requiring HD display.
Supports DC 12V power supply, provides stable power input and ensures stable operation of the device during high performance and multi-tasking. (Pentium/i3 processors recommended 7A, i5/i7 processors recommended 10A)

Application scenarios:

Virtualization Server: Powerful processors and large memory are ideal for virtualization applications and provide an efficient operating platform for multiple virtual machines.
Firewalls and routers: Multiple 2.5G network card configurations and high-performance processing capabilities enable enterprise-class firewalls and routers for high-performance network security and traffic management.
Industrial control systems: High-performance processors and multiple network card configurations are suitable for industrial data acquisition and processing, providing a highly reliable, low-latency control system.
IoT Gateway: Suitable as an IoT gateway to connect and manage multiple IoT devices, process and transmit data.
Data Acquisition and Processing: Multiple high-speed network interfaces and powerful processing capabilities make it suitable for industrial data acquisition and processing tasks.
Digital Signage: The compact design and multiple video output ports are suitable for digital signage and advertising displays, providing high-definition content playback.
Self-service terminal: It can be used as the core computing device of the self-service terminal, providing high performance and low power computing capabilities.
Multimedia Server: As a home media server, the processor's powerful decoding capabilities enable streaming media services and high-definition content playback.
Edge computing: As an edge computing node, it provides localized data processing and storage, reducing latency and bandwidth consumption.
