1264NP-12-4L-MB

Model 1264NP-12-4L-MB
Processor Intel N100/Core i3-N300
Motherboard BKHD-1264NP-12-4L
Network port 4*RJ45
Network controller 4*Intel i226 2.5GbE
Memory 1*DDR5 SO-DIMM 4800MT/s
Storage 1*M.2 Key-M 2280, 1*SATA
Expandable slot
1*mPCIe, 1*M.2 2230 CNVi protocol
Video output 1*DP, 1*HD
Motherboard size 120*120 mm
Power supply DC 12V-4A or higher

Get Sample

BKHD-1264NP-4网-主板 Product Features - Beikong Industrial

Core Product Advantages

Alder Lake-N Platform - Selectable Intel N100/I3-N300 processors for low-power and high-performance scenarios
Full 2.5G Industrial Network - 4×Intel i226 2.5GbE ports with traffic prioritization
Ultra-Compact Design - 120×120 mm mini-ITX form factor for wall/embedded mounting
Wireless IoT Hub - Native CNVi protocol support for WiFi6/Bluetooth 5.2 modules

Typical Application Scenarios

Industrial Edge Gateway - PLC data acquisition and OPC UA protocol conversion
Smart Retail Terminal - DP+HD dual-display for self-service kiosks/digital signage
Mobile Maintenance Device - Wireless modules enable mobile OTA updates
Compact Storage Server - M.2 SSD + SATA for hot/cold data tiering
